- Commodity name: RFlD Security WEB Door Access Controller System
- Commodity ID: FD-R6
Web Based TCP/IP Access Controller Reader
Web Based TCP/IP Access Controller Reader
Feature
Standalone, Sub-Controller, Dummy Reader modes
Card verification mode
Proprietary PC software support
Built-in http serverDatasheet
Software Application： PC Sofware/ Web Server Time Set/Time Zone/Group: 255/120/255 Sets Verification Mode: Card (Not support Keypad) Holiday: Yes Card Capacity: 20,000 Remote Control/Event Handle: Yes/Yes Communications: TCP/IP, Wiegand/RS485 Fast Registry: Yes DIO Interface: DI: 3 / DO: 1 Anti Pass Back: Yes Inbuilt Relays (Max. power loading): Door Lock (40VAC/40VDC,2A) Power Consumption: 500mA±5% Power Requirement: 9~24VDC/1A System Log: 1,536 entries Operation Temperature: 0℃~55℃ Entry Log: 51,968 entries Dimension/Weight: 160x56.9x40.1mm/150g Structure
Frequently Asked Questions
电源适配器在使用过程中发出嗡嗡、吱吱等异常响声
内部元件松动，此时需要专业人员打开适配器外壳并检查内部元件的固定情况。
电源适配器在使用过程中变得过热
1.检查是否连接了过多的设备或设备功率过大，超过适配器的额定功率，可减少连接设备数量或更换更大功率的适配器。
2.清理适配器的散热系统，如散热片是否被灰尘堵塞，风扇是否正常运转
3.可能是适配器内部电路存在短路故障，需专业人员检查并修复。
设备连接电源适配器后，充电速度极慢或无法充电
1.检查适配器的输出电压和电流是否稳定，如不稳定可能是内部电路元件老化或性能下降，需送修或更换。
2.检查充电接口是否松动、接触不良，如有问题可重新插拔或清理接口处的金属触点。
3.可能是设备的电池管理系统出现故障，可尝试重启设备或连接其他正常电源适配器进行测试。
